| Allmänt |
| Typ av enhet | Nätverksadapter |
| Formfaktor | Instickskort |
| Gränssnittstyp (buss) | PCI Express 2.0 x8 |
| Version av PCI-specifikation | PCIe 2.0 |
| Nätverk |
| Portar | 10Gb Ethernet x 2 |
| Anslutningsteknik | Kabelansluten |
| Datalänkprotokoll | 10 Gigabit Ethernet |
| Dataöverföringshastighet | 10 Gbps |
| Protokoll för administration på distans | SNMP |
| Statusindikatorer | Portstatus, länk/akvititet |
| Funktioner | Jumbo Frames-support, teamingssupport, PXE-support, LSO, RSS |
| Standarder som följs | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3p, IEEE 802.3ap, IEEE 802.1au |
| Processor / Minne |
| Processor | 1 x Broadcom BCM57810S |
| RAM | 256 MB |
| Expansion/Anslutning |
| Gränssnitt | 2 x 10Gb Ethernet |
| Kompatibla kortplatser | 1 x FlexibleLOM |
| Diverse |
| Standarder som följs | VCCI Class B ITE, EN 61000-3-2, EN55022, EN 61000-3-3, FCC Part 15 B, WEEE, RoHS |
| Programvara / Systemkrav |
| Operativsystem erfordras | SunSoft Solaris 10, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x |
| Miljöparametrar |
| Min temperatur vid drift | 0 °C |
| Max temperatur vid drift | 55 °C |
| Luftfuktighet vid drift | 10 - 90 % (icke-kondenserade) |
| Kompatibilitetsinformation |
| Designat för | HPE ProLiant DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Special Server, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL388p Gen8 Base, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, SL250s Gen8 2U Left Half Width Tray, SL250s Gen8 2U PCIe Gen3 Left Tray, SL250s Gen8 2U Right Half Width Tray, SL250s Gen8 Base 2U Left Half Width Tray, SL250s Gen8 Base 2U Left Tray Server, SL250s Gen8 Base 2U Right Half Width Tray, SL250s Gen8 Base 2U Right Tray Server, SL270s Gen8 1U Left Half Width Tray, SL270s Gen8 1U Right Half Width Tray, SL270s Gen8 Base 4U Left Half Width Tray, SL270s Gen8 Base 4U Right Half Width Tray, SL270s Gen8 SE 4U Left Tray, SL270s Gen8 SE 4U Right Tray |
|
