- Four 10/100/1000 Mbps switched ports connect desktops, notebooks, printers, access points, IP cameras, or IP telephones
- Two built-in pass-through ports support legacy telephony or additional networking
- Security features include IEEE 802.1x network login, Radius support, SNMP traps and IEEE 802.1Q VLANs
- Power can be forwarded through two ports to other devices
- Compliance with NEMA-WD6 and ANSI commercial building standards helps ensure easy installation
- Mounts securely to the wall using a Torx screw to deter theft or tampering the wall-mounted form factor is more secure than a freestanding hub or switch
HP IntelliJack Gigabit switches are compact 10/100/1000 switches that can be installed in a standard wall outlet box, quickly converting an existing single-port LAN wall outlet into four switched Gigabit Ethernet ports. These "network jacks" provide a simple solution for adding network ports without running more cabling. Unlike conventional desktop switches, HP IntelliJack devices reside out of the way-literally in-the-wall-and so are more secure from theft and difficult to accidentally disconnect or damage. The innovative HP IntelliJack switches provide four Ethernet ports for local connectivity plus one uplink port. Two additional RJ-45 "pass-through ports" flexibly support a range of additional service and user connectivity options. It can be powered locally or via Power over Ethernet (PoE), and can output standard PoE on up to two ports to directly power attached devices such as IP phones or wireless access points.
